Mobile Thermal Printer
Palm Size
Paper Drop in Style
Variable paper width from 34 to 58mm
Can be used for Label Printing
Bluetooth, IRDA & RS232 interface
Large 2200mAh Li-ion rechargeable Battery
Low battery monitoring
Belt Clip
Epson TM88 ( ESC/POS ) command set emulation
Rubberized over-moulding design for 1.2m drop resistance
2 Colour Printing with special paper
Auto power off function
?
Paper | T5750 | Thermal 57 x 50 Paper rolls |
Power Supply (option) | AD9VR27MP | 9 Volt regulated power supply for MP3200 |
RS-232 Cable | CAB-MP232 | RS-232 Cable for the MP3200 |
Printing Method | Line Thermal Dot Printing |
Printing Width | 48mm |
Dot pitch | 203 dpi |
Printing speed | Max. 70 mm/sec |
Bar-code Type | JAN13/8, Code39/128, ITF, NW-7, QR & PDF417 |
Paper | Max. Width 58mm, Thickness 60-65 µm, Max. Diameter 50 mm |
Interface | IrDA Version 1.2 (Up to 38.4 Kbps) |
RS-232C with optional special cable (up to 38.4 Kbps) | |
Bluetooth wireless interface | |
Sensor & Error monitoring | Paper end, Cover-open, Low battery, Head overheat |
Optional Mag stripe reader | Track 1, 2 & 3 |
Power Supply | Li-ion battery 2200mAh |
AC adaptor for charging (output DC 9V, 2.7A) Optional extra | |
Battery | 40,000 print lines per charge (Characters) |
Maximum recharge time: 3 hours | |
Auto power off | 1-60 minutes (default 10 min.) Software selectable. |
Weight | Approx. 520g (with battery & belt clip, w/o paper roll) |
Dimensions (W x D x H) | 99 x 139 x 72 mm |
Operating environment | 5 ~ 40 ºC |
