17″ Inch TFT LCD POS Monitor
350 Nits (cd/m²)
Designed for Customer display Solutions
no Base
VESA Mount
?
Mounting Pole | ATSD-POS-M | Mounting pole with VESA mount 376mm |
Extra VESA mount for pole | ATSD-POS-M-BB | 2nd VESA Mount for SD-POS-M Black |
VGA Cable | CAB-SVGA5m | 5m VGA Cable |
Viewing Area | 17″ TFT LCD |
Resolution | 1280 x 1024 |
Colour | 16.7M |
Response time | 2/3 ms typical |
Contrast Ratio | 1000:1 |
Brightness | 350 cd/m² |
View Angle | 170º (H) / 160º (V) |
VGA Signal | R/G/B Analog VGA |
Scan Frequency | H:31.5~60 kHz / V: 56~75 Hz |
Controls | Brightness, Contrast, H-Phase, V-Phase, size |
Power Supply | External Power Adapter AC 100~240V, 50/60Hz, Output DC12V |
Consumption (Max) | 35 W Max., Standby 2W |
Operating Temperature | 0 ~ 40 ºC |
Operating Humidity | 10 ~ 85% |
External Dimensions (W x D x H) | 401.9 x 57.6 x 326.5 mm |
EMC/Safety Standards | CE, FCCB, TUV/GS, ETL.ETLC, C-Tick |
