Full range AC input 90V~264V
Meet Energy Star EPS 2.0 /ErP Lot 7
No load Power Consumption …0.21W High Reliability
Available for high altitude(5,000M) and DOE level VI
Output Power 60W
Output Voltage & Current 12VDC@5A
Efficiency (%) 88% minimum
Dimension (L x W x H) 110×62.2×31.3mm
Vibration 1g²/Hz at 10500 Hz
MTBF 100,000 hours at 25°C
Operating Temp. (°C) 0 to + 40°C
Safety & EMC Class B
Max Temp. (‹C) @ Load 70C — 80%
Safety Standard CUL (UL 60950) / CB (IEC 60950) / CCC / CE / FCC / GS (EN 60950) / KC / RCM /
Jug cord input
DC Jack
5.5mm outer, 2.5mm inner
