Physical Configuration
Dimension (HxWxD) cm 4.17 x 44 x 27
Fixed Ports 22 x Gigabit Ethernet SFP + 2 x Gigabit combo (RJ45 / SFP) Ports
Flash Memory 64MB
Packet Buffer 0.75MB
SDRAM 256MB
Standalone/Stackable Standalone
Weight (kg) 3.55Kg
• Performance
Forwarding Rate 35.7 Million packets per second
MAC Address Table Size 8K (include 1K static Mac table)
Switching Capacity 48Gbps
• Layer 2 Features
Auto MDI/MDIX
Broadcast/Multicast Storm Control
Flow Control
IGMP Snooping IGMP Snooping v1/v2 | IGMP Snooping v1/v2/v3 | IGMP Throttling | IGMP Filtering | IGMP v1/v2 querier support | IGMP Querier | IGMP Immediate Leave | IGMP SNP Leave Proxy | IGMP v1/v2/v3 Proxy | IGMP snooping v1/v2 proxy reporting
Jumbo Frame
Link Aggregation IEEE 802.3ad with LACP (Dynamic) | Static Trunk | Unicast / Multicast traffic Balance over Trunking port
MAC Address MAC Learning | MAC Flush
Multicast (IGMP) Snooping Immediate Leave | IGMP Filtering | IGMP Throttling | IGMP Leave Proxy | MVR Support
MVR
select QinQ
Spanning Tree IEEE 802.1D (STP) | IEEE 802.1w (RSTP) | IEEE 802.1s (MSTP) | Spanning Tree Fast Forward | BPDU Filtering | BPDU Guard | BPDU Forward | BPDU Transparent | Loopback Detection | Auto Edge Port
Storm Control Broadcast
VLAN 802.1Q VLAN | Private VLAN | GVRP | IEEE 802.1v | Q-in-Q | MAC Based | IP Subnet VLAN | Port Based | Voice VLAN | VLAN Trunking | Traffic Segmentation | GARP | VLAN Translation | IPv6 VLANs (one type which protocol VLAN supported)
VLAN Group 256
• Layer 3 Features
CIDR (Class Inter-Domain Routing)
Dynamic arp 3840
IP interfaces 32
IP Redundancy VRRP RFC3768
IPv6 hardware IP routing
IPv6 Muticast Routing PIM-SM6
L3 IPv4 Host Table 2K
L3 IPv4 Multicast Table 1K (share with ipv6)
L3 IPv4 Net Table 512
L3 IPv6 Host Table 1K
L3 IPv6 Multicast Table 1K (share with ipv6)
L3 IPv6 Net Table 256
MLDv1
MLDv2
Multicast Routing PIM-DM | IGMP v1/v2 RFC2236 | IGMP v2/v3 proxy | IGMP v3 RFC3376 | IGMP v3 proxy | PIM-SM RFC2362
Multi-Netting
OSPFv3
Proxy ARP
Static ARP 1024
Static Route
UDP Helper
Unicast Routing Equal Cost multipath routing(ECMP) | RIP v1/v2 | OSPF
• QoS Features
CoS IEEE 802.1p | IP Precedence | DSCP | TCP/UDP | Port Based priority | Packet Priority for CoS | Overwrite 802.1p priority
DiffServ (RFC2474)
Egress Rate Limiting Per Individual Port
Egress Rate Limiting Resolution 1Mbps
Hybrid (WRR +Strict)
Ingress Rate Limiting Per Individual Port
Ingress Rate Limiting Resolution 1Mbps
Number of pripority queue 8 queues/port
Policy Based Overwriting IP DSCP to 802.1p Priority
Strict Pripority scheduling
WRR Pripority scheduling
• Security Features
AAA Local Authentication | RADIUS authentication | RADIUS accounting | TACACS+ authentication | TACACS+ authorization
ACL Time-Based
ACL L2/L3/L4
ACL Number of Rules Gigabit: per port (36 rules and 67 masks)
Applied Interface Port
Dynamic ARP inspection (DAI)
Dynamic MAC-Based Address Security Per Port
HTTP and SSL (Secured Web)
IEEE 802.1x Port-based | MAC-based | VLAN Assignment | QoS Assignment | Guest VLAN | 802.1x Extensible Authentication (EAP) | 802.1x Multiple Host Multiple Authentication | Guest VLAN with EAP enabled on port | Multiple Host Single EAP Authentication | MAC based EAP Authentication (Clientless EAP) | RADIUS assigned VLAN in MHMA mode | EAP over LAN (EAPOL) | EAPOL frames pass-through | Auto security | Supplicant Support
MAC Based Authentication
MAC Filter
MAC Limitation per port
Management Access Filtering SNMP | WEB | Telnet
SSH v1.5/ v2.0 (Secured Telnet Session)
Static MAC-Based Address Security Per Port
Username/Password Authentication Local | Remote
Web authentication Per port
• Management Features
Auto Traffic Control (ATC)
Banner
BootP
Cable Diagnostic / TDR
CLI “show interfaces brief”
Configuration Download/ Upload
Console
CPU Process Utilization
Delay Reload
DHCP Client | Relay | Snooping | Option 82 | Server | Dynamics Provision
Disable Management Protocols
DNS Client | Proxy
Dual F/W Images
Event/ Error Log Local Flash | Remote Server via System Log (RFC3164) | SMTP (RFC821)
IP Clustering
IP Source Guard
LLDP
MAC Based Mirror
Port Mirroring One to One
Remote Ping
Remote Switched Port Analyser (RSPAN)
RFC 1213(MIB for Network Management of TCP/IP-based internets)
RMON RMON I (1,2,3 & 9 groups)
sFlow
SNMP (Agent) v1 | v2c
SNTPv4 (RFC2030) Yes
Software Download/Upgrade TFTP | HTTP | FTP | Xmodem / Ymodem
Syslog Yes
Telnet Client | Server
Traceroute
UPnP
VLAN Mirror
Web-based GUI
• IPv6 Features
6 to 4 tunnel
Hardware Enabled
HTTP over IPv6
ICMPv6 Redirect (Host)
Interface status
IPv4/IPv6 Dual Protocol stack
IPv6 ACL L2/L3/L4
IPv6 Address Types Unicast | Multicast
IPv6 DHCP Relay
IPv6 DNS Resolver
IPv6 DSCP remapping CoS
IPv6 Management IPv6 Telnet Support | IPv6 Syslog Support | IPv6 FTP support | IPv6 TFTP support
IPv6 Neighbour Discovery Router Discovery | Duplicate Address Detection | Static Cache Entry | Parameter Discovery | Address Resolution | Unreachable Neighbour Detection
IPv6 Path MTU Discovery
IPv6 SNTP Support
IPv6 Telnet Support
Manual Configuration
Manual tunnel
MLD v1/v2 Snooping
Ping over IPv6
Remote IPv6 Ping
Sflow over IPv6
SNMP over IPv6
SSH over IPv6
trace route over IPv6
