Lightweight Design
One handed operation
Solid State Construction.
Operational after multiple drops from 1.0m onto concrete.
Lithium Ion Battery with advanced Power Management System.
Laser Scanner
3 MegaPixel Camera
Windows® Embedded Handheld 6.5
Standard 256Mb RAM, 512Mb non-volatile NAND Flash memory.
WLAN: 802.11b/g, WWAN: GSM/GPRS/EDGE
Standard Bluetooth® Class 2 V1.2
GPS support
2.8″ QVGA 240×320 Transmissive active matrix colour display with touch screen.
29 Key Alpha/numeric-shifted alpha and navigation key
?
Homebase | D60HB | Dolphin® 6000 HomeBase. Single bay charging cradle with USB and serial (RS-232) ports for communications and auxiliary battery well for charging an extra battery. Includes Australia power cord and power supply. |
Mobile Charger | D60MC | Dolphin® 6100 Mobile Charge Cable kit. Includes 12V vehicle charging adapter and terminal cup. |
Cables | CAB-D60-CC | Dolphin 6000 USB Communications & Charging cable kit with snap on terminal connector cup, power supply and Australia / New Zealand power adapter |
Battery | D61BATT | Spare Standard Battery for Dolphin 6000/6100 |
Stylus | D60STYLUS | Stylus and tether kit (3 Pcs) |
Screen Protector | D76SCPROTECT | Screen Protector for Dolphin 6000/7600 (Pack of 6) |
Processor | 416MHz MTK | |
Development Environment | Honeywell SDK for Windows® Embedded Handheld 6.5 and Visual Studio 2008 | |
Application Software | Honeywell Powertools® and Demos; MS SDK; Remote MasterMind RDM | |
3rd Party Software | ITScriptNet™ rapid application development software with Ready To Go applications | |
Operating Platform | Windows® Embedded Handheld 6.5 | |
Memory | 256 MB RAM x 512 MB non-volatile synchronous Flash standard. | |
Memory Expansion | User accessible Micro SD Card up to 8GB | |
Scan engine | Honeywell 1D Laser Scanner | |
Decode Capabilities | Reads Standard 1D Symbologies | |
Camera | 3 MegaPixel autofocus /w LED Flash | |
Keyboard | 29 Key shifted alpha Numeric /w MID keys | |
Display | 2.8″ QVGA colour Transmissive Active Matrix LCD display with 4-wire Resistive Touch Screen | |
Display Resolution | 240 x 320 Pixels | |
I/O Ports | USB charge/Comm Cable USB/RS232 base | |
Audio | Speaker, HAC receiver, microphone, vibrator | |
Wireless Connectivity | WLAN | 802.11 b/g WAPI support |
WPAN | Bluetooth® V2.1 with EDR | |
Wireless Connectivity | WWAN | GSM/GPRS/EDGE voice and data |
GPS | Integrated assisted GPS (AGPS) | |
Battery | Li-ion 5.7 watt-hour | |
Expected Hours of Operation | WLAN/high scanning profile: 8 hours; WWAN & GPS profile: 8 hours; GSM Talk Time: 6 hours; typical runtimes using system default settings | |
Expected Charge time | Less than 6 hours | |
Sealing | Independently certified to meet IP54 standards for moisture and particle resistance | |
Mechanical Shock | Drop: Functional multiple drops from 1.0 m onto concrete across operating temperature range. 1.5 m at room temperature | |
Electrical Static Discharge | Air: 15kVdc Direct: 8kVdc | |
H x W x D | 134 x 65 x 18.5 mm | |
Weight | 200g | |
Operating Temp. | -10 ~ 50°C | |
Humidity | up to 95% non condensing | |
Warranty | 1 year Factory warranty | |
