Handheld Laser Scanner
Automatic trigger operation
RSS Decoding Capability
Supports most popular host interfaces
User-replaceable, single cable interface to host
Easy programming via software or barcodes in the manual
Codegate® data transmission technology
Sunrise 2005 compliant
OPOS and JPOS system compatible
Custom edit the bar code data
Available in Light Grey and Black
?
Adaptor | AD-MS5VR06N | 5V Regulated Power Supply? |
Scan pattern | Single Line |
Scan Rate | 72 +/- 2 Lines/sec |
Width of Field | 49 mm at face, 195 mm at 140 mm |
Depth of Field | 0~140 mm for 13 mil bar codes |
Minimum Bar width | 4 mil |
Light Source | Visible Laser Diode 650 nm +/- 10 nm |
Decoding Capability | Decodes all standard 1D, RSS14, RSS Limited and RSS expanded Barcodes |
Communications | PC Keyboard wedge, RS232, OCIA, Light pen emulation, IBM 468X/469X, Stand Alone Keyboard, USB. |
Shock | Normal operation after 30 drops to concrete from 1.5 m |
Dimensions | (L)16.9 x (H)3.1~3.5 x (W) at handle 4, at Head 6.3 cm |
Weight | 97 g |
Factory Warranty | 3 years |
EMC/Safety Standards | TUV, UL60950(USA), CISPR22-B, IEC60285-1 Class 1 |
