A perfectly balanced, seamlessly integrated high end 5.1 sub/sat system based on KEF’s new 4.25” Uni-Q driver array and a superlative matching subwoofer, the new E305 home theatre system outperforms the competition by filling the room with a spacious, exquisitely detailed and compellingly natural soundscape that captures all the magic of the original performance.
The E305 system is designed to deliver exceptional bass performance, with the sub seamlessly integrated within the rest of the system, so it sounds like five full-range loudspeakers. The frequency and phase response of the sub and satellites are carefully matched to smoothen the transition, so you can’t hear where the satellite stops and the sub starts.
With a large, powerful motor system driving a long throw 8-inch cone, low frequency reproduction remains composed and unerringly accurate, even at high volume. Based on a Linkwitz Transform circuit to minimise any signal group-delay that would otherwise muddy the bass, the on-board pre-amp assures noticeably cleaner and more accurate low frequency reproduction.
A closed-box design, the E-2 subwoofer delivers agile extended bass response without overhang – fast, punchy and well defined. Like the satellites, the cabinet borrows damping technologies from the LS50 to avoid resonance and secondary radiation to ensure tight, clean and immaculately controlled bass.
Model | E301/ E301c |
Design | Two-way bass reflex |
Drive units | Uni-Q driver array: HF: 19mm vented aluminium dome MF: 115mm aluminium |
Frequency range (-6dB) | 80Hz – 45kHz |
Frequency response (±3dB) | 90Hz – 33kHz |
Crossover frequency | 2.7kHz |
Amplifier requirements | 10 – 100W |
Sensitivity (2.83V/ 1m) | 86dB |
Harmonic distortion 2nd & 3rd harmonics (90dB, 1m) | <1% 100Hz – 40kHz |
Maximum output (SPL) | 109dB |
Norminal impedance | 8? (min. 3.4 ?) |
Internal volume | 1.5Litres |
Weight | 2.4kg |
Dimensions (H x W x D) (with grille and base) E301 E301c | 260 x 136 x 159 mm 157 x 220 x 155 mm |
Optional accessories | Floor stands |
Model | E-2 |
Design | Powered Subwoofer |
LF Drive unit | 200mm (8in.) |
Frequency range (-6dB) | 33Hz – 280Hz |
Amplifier | 250W built-in Class-D |
Maximum output (SPL) | 102dB |
Low pass filter variable | Fixed 250Hz, 2nd-order |
Low level signal inputs | RCA phono socket |
Enclosure type | Sealed |
Internal volume | 14.7Litres |
Power requirements | 100 – 240VAC 50/60Hz |
Power consumption | 250VA |
Weight | 7.25kg (16lbs.) |
|
