12″ Inch TFT LCD POS Monitor
180 Nits (cd/m²)
Designed for POS Systems
Sturdy Base
?
Pole Stand | ATSD-POS-M | Atdec POS Pole |
Viewing Area | 12″ TFT LCD |
Resolution | 800 x 600 VGA |
Response time | 6/17 ms |
Contrast Ratio | 350:1 |
Brightness | 250 cd/m² |
View Angle | 120° (H) / 100° (V) |
VGA Signal | Analog VGA |
Scan Frequency | H:30~60 kHz / V: 56~75 Hz |
Controls | Brightness, Contrast, H-Phase, V-Phase, size |
Power Supply | External Power Adapter AC 100~240V, 50/60Hz, Output DC12V |
Consumption (Max) | 35 W |
Operating Temperature | 0 ~ 40 °C |
Operating Humidity | 10 ~ 85% |
External Dimensions (W x D x H) | 305 x 135 x 302 mm |
EMC/Safety Standards | CE, FCCB, TUV/GS, ETL.ETLC |
