Fast (up to 180 mm/sec) Direct Thermal Printing
Drop in Paper loading
Two Colour Printing (with Special Paper)
Barcode Printing, including QR code
Compatibility (ESC/POS)
NV Memory for Bit map Data Storage
Page mode printing
Auto cutter
Firmware downloadable with USB Stick, for easy in the field upgrades
Standard USB plus RS232 or Parallel
Flexible paper widths. (80mm & 58mm)
External Power Supply
Available in Ivory/Black or Black
?
Paper | T8080 | Thermal 80 X 80 Paper Roll |
T5750 | Thermal 57 X 50 Paper Roll | |
T5770 | Thermal 57 x 70 Paper Roll |
Printing Method | Line Thermal Dot Printing | |
Dot Pitch | 180 dpi | |
Printing Speed (Max.) | Mono Printing on 80mm Paper approx. up to 180 mm/Sec (43 Lines/sec) Mono Printing on 57mm Paper approx. up to 150 mm/Sec (36 Lines/sec) Colour Printing approx. up to 100 mm/Sec (24 Lines/sec) | |
Printing width | 80 mm Paper 72mm 57 mm Paper 48mm (max. 54mm) | |
Font Size | Font A: 12 x 24 | |
Font B: 9 x 17 | ||
Number of Columns | 80 mm Paper: Font A – 42 Columns, Font B – 56 Columns | |
58 mm Paper: Font A – 30 Columns, Font B – 40 Columns | ||
Character Size | Font A: 1.69 x 3.38mm (12 x 24 dots) | |
Font B: 1.26 x 2.39mm (9 x 17 dots) | ||
Character Table | Alphanumeric Character (Font A & B) | |
Bar-code Type | UPC-A/E, EAN-13/8, ITF, Code 39/93/128, Codabar. | |
Paper feed method | Friction | |
Paper Type | Thermal Paper Roll | |
Paper Width | 80 ± 0.5mm or 58 ± 0.5mm | |
Paper Roll Diameter | Max Ø 83.0mm | |
Paper Supply Method | Easy Paper Loading, Drop in and Print | |
Emulation | ESC/POS & Star | |
Print Buffer | 64K bytes | |
NV Memory | 8 Mbytes | |
Sensors | Paper End & cover open Sensor. | |
Drawer Ports | 1 ports Controls 2 drawers with special cable. (24V) | |
Interface | USB + RS232 USB + Parallel (special order) | |
Driver available | Windows 2000/NT/XP/2003 server, OPOS | |
Software Utilities | Firmware/NV Image download | |
Power Supply (Adapter) | Input: AC90 ~264V Output: DC 24V,2.5A | |
Operating Environment | 5°~45°C, 30~80% Relative Humidity | |
Storage Environment | -10°~50°C, 10~90% Relative Humidity | |
Weight | 3 Kg | |
External Dimensions (W x D x H) | 144 x 195 x 137 mm | |
Reliability | Head | 100,000,000 Pulses, 150Km |
Mechanism | 70,000,000 Lines | |
Auto Cutter | 1,500,000 cuts | |
EMC/Safety Standards | C-Tick, FCC Class A, TUV-GS, CE, CB, cTUVus | |
