PC POS Touch System
Resistive or IR touch screen
15” LCD 1024 x 768 resolution
Spill-resistant design (IP44 capable) to prevent careless spill and provide easy cleaning for a wide range of applications
Equipped with Intel Sandy Bridge Pentium B950 2.1GHz CPU and DDR3 memory
Fan-free design boasting quiet and anti-dust features
Patented aluminium die-cast housing design for efficient cooling
UPS (Embedded on board developed by Posiflex) support to avoid sudden power loss (Optional Battery pack required).
Push-open cover to protect power switch from accidental shutdown
Bottom cable guide design and cover for safety and neat outlook
User-friendly mechanism for system upgrade and easy maintenance
Available with Bezel free front panel
Optional Shinny black front bezel for stunning look
Standard on Generation 6 super slim base stand
Pole Display | PFPD310B-U | 2 Line 20 Character LCD Display mounted on the rear top of display for the KS series with USB Interface |
2 Line 20 Character VFD Pole Display for the KS7215 with USB Interface | ||
MSR | MSR track 1, 2 & 3 (optional fingerprint sensor) for the KS-7215 | |
MSR track 1, 2 & 3 (optional RFID and/or Wifi module)for the KS-7215 | ||
Keypad | 36-Key Dynakey with key lock attachment. Can also come with MSR | |
2nd LCD Display | 15″ inch 2nd LCD Display for the KS-Series on 300mm Pole (Gen 5 Base) Standard Machine comes with Gen 6 Base | |
15″ inch 2nd LCD Display to mount on back of the Main screen for the KS-Series | ||
15″ inch 2nd LCD Display for the KS-Series with mounting bracket to the base (Gen 6 Base) of main unit. | ||
12″ inch 2nd LCD Display for the KS-Series with GEN 6 Base | ||
UPS Battery | Rechargeable UPS Battery | |
Cables | RJ45 to DB9 Converter Cable | |
Optional Parallel Cable | ||
Cable to be able to fire 24V Cash Drawers | ||
Wall mount Bracket | Wall mount bracket with VESA mount |
CPU | Intel Sandy Bridge Pentium B950 2.1 GHz CPU / 2M Cache |
Memory | DDR3 1066 MHz, SO-DIMM socket x 2, max 8 GB, default 2GB |
Storage | We stock Standard 32GB SSD Also available with higher spec SSD or 3.5 inch 320GB Hard Disk Drive CF Kit is also an option. |
OS Support | WIN 7, Windows XP Pro, POSReady 7, POSReady 2009 |
LCD | 15″ TFT LCD Display |
Tilt Adjustment | From 15° to 70° |
Brightness | 250 nits |
Resolution | 1024 x 768 |
Touch Panel | Normal Bezel: 5-wire Resistive (USB I/F) or optional IR Touch (USB I/F) Bezel Free: Resistive (USB I/F) or optional PC Multi Touch (USB I/F) |
Connectivity | 4 RS-232 Ports (3 x DB9, 1 x RJ45) with 5V/12V support |
Optional: 1 Parallel Port (needs Proprietary Cable) | |
7 USB Ports (6 on I/O Panel and 1 on the side) 1 Proprietary USB port for side mount optional devices Optional Powered USB (1 x 24V), needs Gen 5.5 Base and 150W Power adapter upgrade | |
VGA Port for 2nd Display (D-Sub with 12V Power for Posiflex LCD Monitors) | |
1 Cash Drawer Port (Controls 2 drawers with optional Y-cable) | |
10/100/1000Mb Ethernet Port | |
UPS Port (Battery Optional) | |
Power on wake up | Through Alarm, LAN or Modem |
Operating condition | SSD: 0°~50°C, 20~90% Relative Humidity HDD: 0°~40°C, 20~90% Relative Humidity |
Storage condition | -20°~50°C, 10~90% Relative Humidity |
Sound | 2W Speaker x 2, Line out |
Size (W x D x H) | 378mm x 312mm x 340mm |
Weight | 9.25 Kg |
