OVERVIEW
15” Bezel Free Fanless Wall-mount POS with Intel® IVY Bridge Series Processor
WARRANTY
36 Month Return to Base Warranty
FEATURES
15” TFT LCD (LED backlight) with Bezel Free Resistive or P-CAP Touch (optional)
Fanless Operation with Intel® IVY Bridge Series Processor
Support System Memory Up to 8GB DDRIII SDRAM
Integrated Stereo 2W+2W System Speakers
3 Mounting Options Available
Support 12V/24V Selectable Cash Drawer Ports (via
External Switch)
Support Intel AMT 8.0 Technology
Support SATA 3.0 HDD Bay
Support 12V/24V Powered USB and USB 3.0 Ports
Support Three Independent Displays
Unique Stand Base with Color and Logo Customization on the Back Cover (Option)
Provide a Seamless and Smooth Surface and Resistant to Water, Dust, Grease, and Food Build-up
6 COM, 11 USB, 1 Gigabit LAN, 1 HDMI Port, 1 VGA and 1 Half Size SSD Module
Device Option: MSR, iButton, Fingerprint, IC card reader, RFID and WiFi
Support WiFi (802.11b/g/n) and RFID(13.56MHz) with ISO 15693, ISO 14443 A/B
RoHS Compliance
SPECIFICATIONS
CPU Intel® IVY Bridge Processor Celeron/i3/ i5/i7 Smart cache memory (base on CPU) Intel® QM77 (IVY Bridge)
System Memory 4 GB up to maximum up to 8GB (SO-DIMM 2 x 204-pin DDRIII 1333/1600)
HDD Driver 1 x 2.5″ SATA HDD bay
SSD 1 x Half size SATA SSD module (option)
Main Display
15″ TFT LCD (LED backlight)/1024 x 768
Brightness: 250 cd/ m2
Touch Screen
Bezel free ELO 5-wire resistive touch
Serial Port 3 x External: COM1, COM2 (RS232 with RJ-45 CON.), COM5 (RS232 /
RS422 / RS485 with RJ-45 CON.)
3 x Internal : COM3 (T/S) ,COM4 (VFD), COM6 (reserve)
USB Port 6 x External: 4 x USB2.0, 2 x USB3.0 ; 5 x Internal USB (for Fingerprint, IC card reader) (3 x reserve)
Output HDMI & VGA port
Audio 1 x Line out, integrated stereo 2W + 2W speakers
Ethernet 1 x RJ-45 Gigabit Ethernet (10/100/1000)
Parallel Port 1 x Bi-directional Parallel ( D-Sub25 )
Cash Drawer RJ-11, 12V(default) / 24V, 1 connector control 2 cash drawer
Power Button Power Switch (LED inside)
Mounting Option Stand Base: Counter Top Base, adjustable View Angle (default)
Wall Mount: VESA Mount Bracket
Pole Mount: Swing-arm Mounts, adjustable angle VESA
Software OS Support XP Pro Embedded , Windows Embedded POSReady 2009, WEPOS, Linux, Windows 7 Pro Embedded, POSReady 7
