The Aopen eTile 19M is an 18.5-inch ultra-slim LED digital signage terminal designed for versatile display applications. Its sleek profile and modern design make it an ideal choice for retail environments, information kiosks, and corporate settings. Featuring high-resolution visuals and energy-efficient technology, this terminal ensures vibrant content delivery while minimizing power consumption. With easy installation and robust connectivity options, the Aopen eTile 19M is a reliable solution for engaging audiences and enhancing communication.
Ultra-thin Multi media all in one Touch System
PCT Multi Touch Touchscreen
IP65 Grade Dust and Waterproof to the Front
18.5” LED LCD Screen 1366 x 768 resolution
Equipped with Intel® B980 Pentium® Dual Core 2.4 GHz CPU 2M Cache
4G DDR3 memory expandable to 8G
Also available with Intel® Core™ i3, i5, i7 mobile Processor
Wifi | AOWIFI-ET | Optional Wifi card, Antenna build in |
CPU | Intel® 2nd and 3rd generation Intel® B980 Pentium, Intel® Core™ i3, i5, i7 mobile processor TDP=35W |
Chipset | Intel® QM77 |
Memory | DDR3 SO-DIMM socket x 2, max 8 GB, default 4GB |
WatchDog Timer | 1 ~ 255 sec/min |
Storage | We stock Standard 320G HDD Also available with SSD |
LCD | 18.5″ LED LCD Display |
Brightness | 250 nits |
Resolution | 1366 x 768 |
Aspect Ratio | 16:9/HD |
Touch Panel | PCT Multi Touch Surface (10 point touch) Pencil Hardness = 7H per ASTM D3363 Pen Hitting: more than 20,000,000 times (loading180g) |
Connectivity | 2 x RS-232 Ports |
2 x USB 2.0 Ports 2 x USB 3.0 Ports | |
1 x HDMI Port | |
1 x 10/100/1000Mb Ethernet Ports | |
Mini card Slot; 1 x Full size (support mSATA), 1 x Half Size | |
Audio | Realtek ALC886 |
Sound | 2W Stereo Speaker in the main unit |
Size (W x D x H) | 448mm x 30mm x 284 mm |
Weight | 5 Kg |
