Mechanical individual keys with membrane contact switches (FTSC technology)
Designed for continuous usage – over 50 mill. Confirmations per key
Robust and reliable
Programmable magnetic card reader
Optional barcode decoder. Data is converted to “scan codes” and transmitted via the PS/2 interface (like normal key operations)
43 programmable keys
OPOS and JavaPOS for Windows® and Linux, client-server architectures supported
Efficient configuration with professional Cherry Tools Software
Integrated memory
Keyboard | Key technology: FTSC Inscription technology: Laser Service life, standard key: > 50 million key operations Number of Keys: 104 Number of programmable keys: 43 |
MSR | Magnetic card tracks: Track 1, Track 2, Track 3 Freely programmable Magnetic card standards: ISO 7811/-12, JIS 1/2, AAMVA, Magnetic card reading speed: 8 – 318 cm/s Magnetic card reading cycles: approx. 800000 reading cycles Magnetic card swipe direction: from right to left |
Interface | USB or PS2 |
Cable Length | approx. 1.75 m |
Current Consumption | typ. 35 mA |
Operating Temperature | 0°C to 50°C |
Storage Temperature | -20°C to 60°C |
Dimensions | approx. 405 x 220 x 64 mm |
Weight | 1.65 Kg |
Reliability | MTBF > 100,000 Hours MCBF > 10 bill. operations |
Product compliance | C-tick, cURus, VDE GS, CE, FCC |
Warranty | 2 Year limited factory warranty |
