Membrane Technology Keyboard
Common Criteria EAL 3+ certified for electronic signatures
Secure PIN entry
PC/SC Smart card reader
CT-Api and OCF support
Protocols: T=0, T=1, S=8, S=9, S=10
EMV 2000 Level 1 approved
CCID compatible
Reading/writing ISO 781-compliant chipcards
Keyboard | Key technology: NTK Membrane Inscription technology: Laser Service life, standard key: > 20 million key operations Number of Keys: 104 |
Smart-Card Reader | Hardware interface: USB Agency Approvals: Product dependant, see table “Models” Chip-card protocols: T=0, T=1, S=8, S=9, S=10 Contact: mechanical swipe reader Software interface: CT-Api, PC/SC, CCID Mating cycles: approx. 100,000 operations Compatible chip card types: Reads and writes on all ISO7816 cards Transmission speed reader <==> card: 412,903 Bit/s Transmission speed reader <==> system: max. 12 MBit/s Chip card pulse frequency: 4.8 MHz |
Interface | USB |
Cable Length | approx. 1.75 m |
Current Consumption | Max. 100 mA |
Operating Temperature | 0°C to 50°C |
Storage Temperature | -20°C to 60°C |
Dimensions | approx. 458 x 170 x 52 mm |
Weight | 1.25 Kg |
Product compliance | C-tick, UL, VDE GS, VCCI, CE, FCC, BG-GS, FIPPS 201 |
Warranty | 2 Year limited factory warranty |
