Easy ribbon loading: Hi-Lift™ metal mechanism opening to a full 90° to allow for easy ribbon access
Heavy duty metal case for strength and durability
Ribbons up to 450 metres long either inside or outside wound with ARCP™ ribbon control
Power switch is conveniently located at the front of the printer
Large graphic LCD for clear indication of printer status and easy printer configuration
Soft-close top cover for user safety and user courtesy
Parallel, serial and USB interfaces standard; optional Ethernet and Wireless LAN
Cross-Emulation™: Supports both Datamax® and Zebra® emulations and will sense the language being used and offer to switch emulations automatically
Drivers: Ships with Windows™ 2000, XP, and Vista drivers
Media capacity: Internal 203mm (8-inch) media capacity
CLP7xxR: Rewind model
Auto cutter | CLPAC621 | Autocutter for the CLP/CLS521/621/631 & CLS700/703 |
Peeler | CLP6PEEL | Peeler for the CLP/CLS521/621/631 & CLS700/703 |
Ethernet Interface | CLP6ETH | Ethernet Interface for the CLP/CLS521/621/631 & CLS700/703 |
Labels | LAB100100PWS40 | Thermal Labels 100 x 100 White, Permanent adhesive, 40mm Core |
Many other sizes available | Please Call our Sydney Office on: 02-8875 4544 |
Printing Method | Thermal Transfer or Direct Thermal printing | |
Printing Speed (Max.) | CLS700/700R up to 254 mm (10 inches) per second CLS703/703R up to 200 mm (8 inches) per second | |
Print Density | Adjustable with software | |
Fonts | 1 Scalable, 8 Bitmap, OCR-A & B | |
True type Download | Supported Standard | |
Emulation | Datamax® (DMX400™, Prodigy Plus®, I-Class®) and Zebra®(Z4M®, ZM400®, Stripe 600® and TLP-2844Z®) on board. Printer will sense the language being used and offer to switch emulations automatically | |
Media Type | Roll or Fanfold; Continues or Perforated; die cut labels; Tags & Tickets | |
Media Sensing | Label Gap, notch or reflective | |
Resolution/Dot pitch | CLS700/700R: 203 dpi, 8 dots/mm CLS703/703R: 300 dpi, 8 dots/mm | |
Media width (Min-Max) | 25.4 – 118 mm | 1 – 4.65 inches |
Label width (Min-Max) | 7.62 – 118 mm | 0.3 – 4.65 inches |
Media Roll Size (Max) | 203 mm, 8 inches (Internal); Media core 38 – 76 mm, 1.5-3 inches | |
Media Thickness (Min-Max) | 0.0635 – 0.254 mm | 0.0025 – 0.01 inches |
Printing width (Max) | 104 mm | 4.1 inches |
Printing length (Max) | 812 mm | 32 inches |
Label length (Min) | 6.35 mm | 0.25 inches |
Ribbon Type | Wax, wax/resin or resin type | |
Ribbon Size | 450 metre, 1476 feet | |
Bar-code Symbologies | Code39, Code93, ITF, Codabar, UPC-A/E, EAN-8/13, UPC and EAN 2 and 5-digit extensions, Plessey, Postnet, Interleaved 2 of 5, Code128 with subsets A/B/C and UCC Case Codes, Telepen, FIM & HIBC. 2D Codes: PDF-417 & Maxi Code | |
Standard Interface | Parallel | IEEE1284 (Compatible, Nibble, ECP Mode) |
Serial | RS232C, Baudrate from 2400-115200 | |
USB | Full Speed USB1.1 | |
Optional Interfaces | Ethernet LAN | |
WiFi, Wireless LAN | ||
Memory | DRAM | 16.0 Mb (1.0Mb for user data) |
Flash Memory | 4.0 Mb (1.0Mb for user data) | |
User Interface | Graphic LCD with 4 buttons | |
Weight | CLS700/703:13.5 Kg CLS700R/703R: 17.6 Kg | |
External Dimensions (W x D x H) | CLS700/703: 255 x 490 x 265 mm CLS700R/703R: 255 x 490 x 385 mm | |
Safety Compliance | UL, C-UL, FCC : class A, CE Marking | |
Power | AC100 – 240V (-10% + 65), 3.0 – 1.5 V, 50 / 60Hz | |
