The DA-250DH is a 2-Channel 100V Line Class D Power Amplifier, featuring lightweight, compact, high power output, and high efficiency.
It delivers 2x 250W per channel using dedicated amplifier stages and seperate switching mode power supplies.
It can be mounted in an EIA Standard 1RU slot.
Product Specification
Power Source | 220 – 240 V AC |
---|---|
Amplification System | Class D |
Power Consumption | 120 W (based on EN standards) 580 W (rated output 100 V line |
Input | 2 circuits 10 kO XLR-3-31 type connector CH 1 mode ON/OFF switch (ON: PARALLEL |
Rated Output | 2 channels: 250 W × 2 (100 V line M4 screw terminal |
Frequency Response | 50 Hz – 20 kHz (-3 dB |
Total Harmonic Distortion | 0.1 % (1 kHz) 0.3 % (100 Hz – 20 kHz) |
Protection Circuit | Protection against excessive current flow due to overload short circuit temperature rise at power amp. heat sink (100 ? (212 ?F) or more) temperature rise inside the unit (80 ? (176 ?F) or more) |
S/N Ratio | 100 dB (A-weighted) |
Crosstalk | 70 dB (A-weighted) |
LED Indicator | Power (blue) × 1 Protect (red) × 2 |
Cooling | Forced air cooling |
Operating Temperature | -10 ? to +40 ? (14 ?F to 104 ?F) |
Operating Humidity | 90 %RH or less (no condensation) |
Finish | Panel: Aluminum Case: Plated steel sheet |
Dimensions | 482 (W) × 44 (H) × 401.8 (D) mm (18.98 × 1.73″ × 15.82) |
Weight | 5.3 kg (11.68 lb) |
Accessory | Power cord (2 m (6.56 ft)) …1 Tamper-proof cap …2 |
Warranty | 3 years |
