Sharp and Bright 3.5” display Colour display with touch screen
Ergonomic, compact and robust
Windows CE 6.0 or Windows Mobile 6.5 Operating System
Integrated Laser Scanner or 2D Imager Scanner with Green Spot or Auto Ranging Laser.
Ruggedized (IP64 & 1.8m Drop)
User Accessible MicroSD memory slot
Bluetooth® wireless technology
802.11b/g Wireless LAN.
Optional 3 MPixel autofocus camera
Cradles | DLX3-DCBASE | Single Cradle Desk RS232/Micro USB + Spare Battery Charging with Power Supply & Micro USB Cable |
DLX3-QBASE-E | Multi Cradle Ethernet (4 slot) | |
Adaptor | AD-DLELDOCK | Regulated Power Supply for Single Slot dock, included with the dock |
Battery | DLX3-STBATT | Standard Battery |
Holster | DL44-HOLSTER | Belt Holster with swivel |
Screen Protector | DLBJ-SCRPROTECT | Screen Protector Kit for 3.5″ Displays, 5 Pack |
Pistol Grip | DLX3-TRHANDLE | Trigger Handle with Mounting Screws for Falcon X3 |
Stylus | DLX3-STPEN | Stylus Pen, Telescopic, 10 Pcs |
Processor | Parallel computer architecture Intel X-Scale PXA310 and Cortex-M3 Processors | |
Development Environment | Datalogic Windows SDK™ | |
JAVA Virtual Machine | ||
Wavelink® Studio™ | ||
Wavelink® Terminal Emulator | ||
Datalogic Desktop Utility | ||
Operating Platform | Windows CE 6.0 with Microsoft Wordpad and Internet explorer 6.0 or Windows Mobile 6.5 with Mobile Tools: Outlook Mobile, Word Mobile, Excel Mobile, Powerpoint Mobile, One note Mobile and Internet Explorer Mobile 6.0 | |
Memory | 256MB | |
Flash Memory | 256MB | |
I/O Slots | 1 x Micro SD slot (SDHC Compatible), User-accessible | |
Scan engine | High Performance Laser scanner with Green Spot | |
Auto ranging Laser (XLR) | ||
Wide Aspect 2D Imager with Green Spot | ||
Laser Characteristics | Scan Rate: 40 +/- 6 Scan/sec Minimum resolution: 0.20mm, 7.5 mils Depth of field: 8 to 91 cm, depending on bar code density XLR: on non reflective labels from 5 to 243 cm on reflective labels up to 1376 cm | |
Imager Characteristics | Scan Rate: 60 Frames/sec Min. resolution: Linear codes @ 4 mils, 2D codes @ 5 mils Resolution: Wide VGA (762 x 480), 256 Gray Scale Image formats: BMP, JPEG | |
Symbologies support |
Laser | GS1 Databar, EAN/UPC, Code 39, 2/5 Codes,Plessey, Codabar, Code 128, EAN128, MSI,Code 93, Code 11 |
Symbologies support |
2D Imager | UPC A, UPC E, EAN 8, EAN 13, Interleaved 2 of 5, Code 39, Code 39 Full ASCII, Codabar, Code 128, EAN 128, Code 93, PDF417, DataMatrix, QR, Macro PDF, GS1 Databar, POSTNET, PLANET, Japan Post, Australia Post, KIX Code, Royal Mail RM4SCC |
Keyboard | Polycarbonate hard cap keyboards. 29 Numeric Keys or 52 Key Alpha-Numeric Keys | |
Display | Transflective TFT daylight readable colour display, 240 x 320 pixels, 3.5″ diagonal, 64K colours, 200 nit backlight, touch screen | |
Communications Ports | RS232 via optional Cable USB OTG with 500mA Power output Dock Communications: USB OTG & RS232; Ethernet optional | |
Radio (options) | WLAN | Integrated Wi-Fi IEEE 802.11a/b/g frequency range country dependent, CISCO Compatible |
PAN | IEEE 802.15 Bluetooth® Class 2 with EDR | |
Battery | Lithium ion 3.7V | |
5000 mAh | ||
Sealing | IP64 | |
Mechanical Shock | Functional after 18 drops from 1.8m onto concrete | |
H x W x D | Standard | 225 x 88 x 55 mm |
Pistol Grip | 225 x 88 x 168 mm | |
Weight | Standard | 626g |
Pistol Grip | 699g | |
Operating Temp. | -20° to 50° C | |
Humidity | 5-95% non condensing | |
