| UFB Ready: | ? | 30/10 | ? | 100/50 | ? | 200/200 |
The DrayTek Vigor2760 version ‘D’ model has all the same hardware features as the Vigor2760 but has the DayOS operating system.
VDSL2/ADSL2+ Router with 4-port Gigabit LAN Switch
- Built-in VDSL2/ADSL2+ modem
- 4 x Gigabit LAN ports for high speed network connectivity
- UFB Ready – LAN port 4 can be configured as a WAN interface and can be used for UFB connections.
- 30,000 NAT sessions
- IPv6 for next generation broadband readiness
- 2 x USB ports for USB Hard Drive or Printer Sharing
- 2 x VPN tunnels with hardware accelerator
- Comprehensive protocols for easy home/office communications
- Object based SPI firewall with Dos/DDoS defence, Web Content Filter, Content Security Management, etc. for maximum network security
- QoS (Layer 2&3, 802.1P, TOS/DCSP) for prioritizing video, voice, online game and data traffic
- TR-069 remote access and management tools for simplifying administrators’ tasks
- 2 year warranty
Features:
ADSL/VDSL
- Compliant with ITU-T VDSL2 G.993.2
- Compliant with ITU-T G.993.1, G.997.1
- Band Plan: 998, 997
- Annex A, Annex B
- VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
- UPBO, DPBO Supported
- US0 Supported
- Capability Fall back to ADSL2/2+ Standards
- Multi-VLAN
- Multi-PVC
- Supports Hardware NAT
Switch
- Multiple Subnets
- 802.1q Bridge
- IGMP Snooping
WAN Protocol
- DHCP Client
- Static IP
- PPPoE
- PPPoA
Content Security Management
- IM/P2P Applications Filter
- URL Content Filter
- Optional GlobalView Web Content Filter (Powered by commtouch)
Firewall
- DMZ Host, Open Port, Port-redirection
- Object-based Firewall
- MAC Address Filter
- SPI (Stateful Packet Inspection) (Flow Track)
- DoS/DDoS Prevention
- Web Syslog
- Logging via Syslog
- E-mail Alert
- Bind IP to MAC Address
- Time Schedule Control
VPN
- 2 VPN Tunnels
- IPSec LAN to LAN , PPTP Remote Dial in
- Encryption : 3DES, AES, DES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared Key (X.509)
- DPD (Dead Peer Detection)
- VPN Pass-through
- L2TP over IPSec Remote Dial in
- PPTP MPPE
- Aggressive Mode
Network Features
- DHCP Server/Client
- DHCP Option
- UPnP 30 sessions (at least)
- IGMP V2/V3
- DNS Cache/Proxy
- Dynamic DNS
- NTP Client
- Static Routing
- RADIUS Client
- RIP V2
Network Management
- Web-based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, Telnet/SSH)
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via WUI
- Multi-level User Management
- Administration Access Control
- Logging via Syslog
- Management Session Time out
- SNMP Management MIB-II
- Data Flow Monitor
- TR-069
- Bandwidth Management
- Layer 3 QoS by Ethernet Type, VLAN ID, TCP/UDP Port, DSCP, ToS, Tag Priority
- Bandwidth/Session Limitation
USB
- Printer Sharing
- File System: FAT32/FAT16/NTFS File System
- FTP Function for File Sharing
Hardware Interface
- 4 x 10/100/1000Base-Tx LAN Switch, RJ-45
- 1 x ADSL2/2+ / VDSL2 WAN Port, RJ-11 for Annex A/RJ-45 for Annex B
- 2 x USB Host 2.0 (for Printer, File System and 3.5G Backup)
- 1 x Factory Reset Button
- 1 x Power on/off Button
