DrayTek DV120-10 in New Zealand
Order DrayTek DV120-10 from ACP Online New Zealand. It forms part of our carefully organised ADSL VDSL catalogue for retail, office, security and technology environments.
Product information
The Draytek Vigor120 is a high speed ADSL2/2+ modem with powerful NAT, Firewall and network management functions.
With an Ethernet connection, this low cost modem router supports not only NAT, but also PPPoE/PPPoA relay. This feature (also called PPPoE to PPPoA Bridging or PPPoE to PPPoA Transparent Pass Through) allows LAN devices to use PPPoE protocol to access an ISP who uses PPPoA protocol. It means that this modem router is more universally useable than modems that only offer PPPoE access.
Like all other DrayTek Vigor series routers, the inbuilt Firewall is Object based, which means that Firewall rules for IP packet filtering, traffic control, URL content filtering, DDoS, can be profiled into groups and tied to a time scheduler for flexibility and easy setup.
As well as traditional Network Management tools such as CLI, Web Based GUI, built-in diagnostics, etc., this modem router also supports TR-069 for central management system (such as DrayTek's VigorACS) allowing ISPs to remotely access and configure their customers routers.
Although low cost, the Vigor 120 supports network features such as DDNS, DNS cache/proxy, UPnP. It also supports IGMPv2 proxy which is essential for IPTV applications.
For existing DrayTek users, the Vigor120 is the ideal modem for multi-WAN or broadband routers such as VigorPro5510, Vigor2920/2930/2950 and Vigor2820 series.
Key Features
PPPoE to PPPoA Bridging – or PPPoE to PPPoA Transparent Pass Through
TR-069 for central management
Complies with full range of ADSL, ADSL2/2+ standards
Easy installation and support
Firewall facilities for network security
Compact design for home office, small office and residential users
Hardware Specification
ADSL: 1-port, ADSL 2/2+ (RJ-11 connector)
LAN: 1-port 10/100 Base-TX Switch (RJ-45 connectors)
ADSL Compliant (DSL)
ANSI T1.413 Issue2
ITU-T G.992.1 G.dmt
ITU-T G.992.2 G.lite
ITU-T G.992.3 ADSL2 G.dmt.bis
ITU-T G.992.5 ADSL2+
Annex L (READSL)
Annex M (Up to 3.5Mbps upstream)
ADSL WAN Protocols
PPPoE/PPPoA relay (PPPoA to PPPoE bridging)
RFC-2684/RFC-1483 multiple protocol over AAL5
RFC-2516 PPP over Ethernet
RFC-2364 PPP over AAL5
PPPoE pass-through from LAN
Transparent Bridge for MPoA
Supports 4 PVC
Firewall
Object-based Firewall
Multi-NAT, DMZ Host, Port-Redirection and Open Port
Stateful Packet Inspection (SPI) flow track
DoS/DDoS prevention
User-configurable IP packet filtering
Content Filtering
URL keyword blocking (whitelist and blacklist)
Java applet, cookies, Active X, compressed, executable, multimedia file blocking
Time schedule control
Network Features
IGMPv2 proxy (IPTV)
DHCP client/relay/server
Dynamic DNS
SNTP client
Call scheduling
DNS cache/proxy
Universal Plug'n'Play (uPnP) compliant
Router Management
Web-based user interface (HTTP/HTTPS)
Quick Start Wizard
CLI (Command Line Interface, Telnet/SHH)
Administration access control
Configuration backup/restore
Built-in diagnostic function
Firmware upgrade via TFTP/FTP/HTTP/TR-069
Syslog
TR-069
Physical Characteristics
White ABS Case
LED status indicators
Dimensions (mm) : L 106 x W 90 x H 26
Weight : 130 grams approx
Maximum Power Consumption : 8 Watt
Client O/S Compatibility
Windows 95/98/ME/NT4/2000/XP/Vista
Linux
MacOS8/9/X
Product details
- Brand: DrayTek
- SKU / model reference: DV120-10
- Product category: Networking › Routers › ADSL VDSL
- Catalogue status: Send enquiry to confirm stock and current pricing.
Before ordering
Please confirm model, connection, sizing, consumable or device compatibility where applicable. Product images and references should be checked against your existing equipment before purchase.
