UFB Ready: | ? | 30/10 | ? | 100/50 | ? | 200/200 |
DrayTek Vigor 2760N VDSL2/ADSL2+ Router with 4-port Gigabit LAN Switch
- Built-in VDSL2/ADSL2+ modem
- Built-in 802.11n 300Mbps Wireless AP with Multiple SSID and Wireless Isolation
- 4 x Gigabit LAN ports for high speed network connectivity
- UFB Ready – LAN port 4 can be configured as a WAN interface and can be used for UFB connections.
- 30,000 NAT sessions
- IPv6 for next generation broadband readiness
- 2 x USB ports for USB Hard Drive or Printer Sharing
- 2 x VPN tunnels with hardware accelerator
- Comprehensive protocols for easy home/office communications
- Object based SPI firewall with Dos/DDoS defence, Web Content Filter, Content Security Management, etc. for maximum network security
- QoS (Layer 2&3, 802.1P, TOS/DCSP) for prioritizing video, voice, online game and data traffic
- TR-069 remote access and management tools for simplifying administrators’ tasks
- 2 year warranty
Features:
Wireless AP
Support 2T2R 2.4GHz, Single Band
IEEE802.11n Compliant
64/128-bit WEP, WPA/WPA2
Hidden SSID
MAC Address Access Control
WPS
Wireless Client List
Access Point Discovery
WDS (Wireless Distribution System)
Multiple SSID
WMM
ADSL/VDSL
Compliant with ITU-T VDSL2 G.993.2
Compliant with ITU-T G.993.1, G.997.1
Band Plan: 998, 997
Annex A, Annex B
VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
UPBO, DPBO Supported
US0 Supported
Capability Fall back to ADSL2/2+ Standards
Multi-VLAN
Multi-PVC
Supports Hardware NAT
Switch
Multiple Subnets
802.1q Bridge
IGMP Snooping
WAN Protocol
DHCP Client
Static IP
PPPoE
PPPoA
Content Security Management
IM/P2P Applications Filter
URL Content Filter
Optional GlobalView Web Content Filter (Powered by commtouch)
Firewall
DMZ Host, Open Port, Port-redirection
Object-based Firewall
MAC Address Filter
SPI (Stateful Packet Inspection) (Flow Track)
DoS/DDoS Prevention
Web Syslog
Logging via Syslog
E-mail Alert
Bind IP to MAC Address
Time Schedule Control
VPN
2 VPN Tunnels
IPSec LAN to LAN , PPTP Remote Dial in
Encryption : 3DES, AES, DES
Authentication : MD5, SHA-1
IKE Authentication : Pre-shared Key (X.509)
DPD (Dead Peer Detection)
VPN Pass-through
L2TP over IPSec Remote Dial in
PPTP MPPE
Aggressive Mode
Network Features
DHCP Server/Client
DHCP Option
UPnP 30 sessions (at least)
IGMP V2/V3
DNS Cache/Proxy
Dynamic DNS
NTP Client
Static Routing
RADIUS Client
RIP V2
Network Management
Web-based User Interface (HTTP/HTTPS)
Quick Start Wizard
CLI (Command Line Interface, Telnet/SSH)
Configuration Backup/Restore
Built-in Diagnostic Function
Firmware Upgrade via WUI
Multi-level User Management
Administration Access Control
Logging via Syslog
Management Session Time out
SNMP Management MIB-II
Data Flow Monitor
TR-069
Bandwidth Management
Layer 3 QoS by Ethernet Type, VLAN ID, TCP/UDP Port, DSCP, ToS, Tag Priority
Bandwidth/Session Limitation
USB
Printer Sharing
File System: FAT32/FAT16/NTFS File System
FTP Function for File Sharing
Hardware Interface
4 x 10/100/1000Base-Tx LAN Switch, RJ-45
1 x ADSL2/2+ / VDSL2 WAN Port, RJ-11 for Annex A/RJ-45 for Annex B
2 x USB Host 2.0 (for Printer, File System and 3.5G Backup)
1 x Factory Reset Button
1 x Power on/off Button
