The EdgeCore ECS2000 series, Layer 2 managed switches enable networks of all sizes to introduce Gigabit Ethernet to the desktop with management features targeted to meet the needs of the SMB network. They are packed with features and are a cost-effective solution that brings continuous availability, QoS priority queuing with classification, and prioritization at Layer 2. They deliver wire-speed switching performance on all ports connecting end stations to the corporate network. There are two SFP ports for Gigabit Ethernet fiber uplink flexibility. Optional Gigabit Ethernet SFP transceivers can be installed for various fiber uplink distances. An embedded user-friendly web interface helps users quickly and simply configure switches. SNMP v1/v2 are supported for management from a network management station. Telnet and SSH provide a safe and easy way for network administrators to manage the switch. This Edge-Core switch also supports management functions through both IPv4 and IPv6. Dimensions (W x D x H) cm: 44 x 28 x 4.4
General Features | |
| Description | 16 10/100/1000BASE-T RJ-45; 2 GE SFP slots |
| Physical Configuration | |
| Dimension (HxWxD) cm | 4.4 x 43 x 18 |
| Fixed Ports | 16 |
| Weight (kg) | 1.91 |
| L2 Features | |
| Auto MDI/MDIX | Yes |
| Autonegotiation | Yes |
| Flow Control | Yes |
| IGMP Snooping | v1 | v2 | v3 |
| Immediate Leave | Yes |
| Jumbo Frame | Yes |
| Link Aggregation | IEEE 802.3ad with LACP (Dynamic) |
| Spanning Tree | IEEE 802.1D (STP) | IEEE 802.1w (RSTP) | Auto Edge Port |
| Storm Control | Broadcast | Multicast | Un-known Unicast |
| VLAN | IEEE 802.1Q Tagged Based | Private VLAN | Port Based | Voice VLAN |
| VLAN Group | 4K |
| QoS Features | |
| CoS | IEEE 802.1p | IP Precedence | DSCP | TCP/UDP | ACL |
| H/W Queues | 8 |
| Priority Queue Scheduling | WRR | Strict Priority | Hybrid |
| Rate Limiting | Ingress | Egress |
| Security Features | |
| ACL L2/L3/L4 | Yes |
| HTTP and SSL ( Secured Web) | Yes |
| IEEE 802.1x | Port-based | MAC-based | VLAN Assignment | Guest VLAN | QoS assignment |
| IP Source Guard | Yes |
| MAC Filter | Yes |
| Port Security (MAC Based) | Static | Dynamic |
| RADIUS (RFC2138) | Authentication | Accounting |
| SSH v1.5/ v2.0 (Secured Telnet Session) | Yes |
| TACACS+ | Accounting |
| Username/Password Authentication | Local | Remote |
| Management Features | |
| Cable Diagnostic | Yes |
| CLI | Yes |
| DHCP | Client | Relay | Option 82 | Snooping |
| DNS | Client | Proxy |
| Event/ Error Log | Local Flash | Remote Server via System Log (RFC3164) |
| LLDP | Yes |
| Loop Detection | Yes |
| Port Mirroring | One to One | One to Many |
| RMON | RMON I (1,2,3 & 9 groups) |
| sFlow | Yes |
| SNMP (Agent) | v1 | v2c | v3 |
| SNTP | Yes |
| Software Download / Upgrade | HTTP |
| Telnet (RFC854) | Yes |
| UPnP | Yes |
| Web Based Management | Yes |
| Web Interface | Yes |
| IPv6 Features | |
| ICMPv6 | Yes |
| ICMPv6 Redirect | Yes |
| IPv4/IPv6 Dual Protocol Stack | Yes |
| IPv6 Address Types | Unicast |
| IPv6 Management | SNMP over IPv6 | Remote IPv6 Ping | HTTP over IPv6 | DHCP IPv6 |
| IPv6 Neighbor Discovery | Yes |
| Stateless Auto-configuration | Yes |
| The listed specification is subject to change without prior notice | |
