Rugged Ergonomic lightweight Design
-
Superior 3.5? Outdoor-Viewable VGA Display
-
Solid State Heavy Duty Construction, No moving parts!
-
Operational after multiple drops from 1.5m onto concrete
It can sustain up to 2000 tumbles from 0.5 meter
-
Lithium Ion Battery with advanced Power Management System. 2 options available.
-
Powered by Adaptus™ Imaging technology 6.0
-
Standard Range or extended Range Area Imager/scanner with Laser aimer or High Density Imager with green LED Aimer
-
Microsoft Windows Embedded Handheld 6.5
-
Fast and Reliable Wireless Connectivity
-
Powerful Processor and Network Connections
-
Remote MasterMind® Ready
-
Numeric or QWERTY Keyboard
?
|
Homebase |
Dolphin® 7800 HomeBase™, charging cradle with USB & RS232 communications ports plus extra well to charge extra battery |
|
|
D7800EHB |
Dolphin® 7800 HomeBase™, charging cradle with Ethernet, USB & RS232 communications ports plus extra well to charge extra battery |
|
|
Charger |
QuadCharger™ 4 slot Battery charger for Dolphin 7800 Batteries |
|
|
Power Supply |
AD-D99EX-QHE |
Power Supply for QuadCharger, Homebase & eBase |
|
AD-G99EX-NC |
Power Supply for NetBase & ChargeBase |
|
|
Cable |
Dolphin 7800 USB Client Charging and Communications Cable with snap on terminal connector cup – kit includes power supply, power cord and AU/NZ adapter |
|
|
Battery |
D7800STBATT |
Spare standard Battery for Dolphin 7800 |
|
D7800EXBATT |
Spare Extended Battery for Dolphin 7800 |
|
|
Holster |
D7800HOLSTER |
Dolphin 7800 carrying holster with integrated belt clip and spare battery pouch |
|
Stylus |
D7800STYLUS |
Dolphin 7800 stylus with tether kit, 3 per pack. |
|
Screen Protector |
D7800SCPROTECT |
Screen Protector for Dolphin 7800 (Pack of 3)? |
|
Processor |
800 MHz TI OMAP |
|
|
Development Environment |
Honeywell SDK for Windows® Embedded Handheld 6.5 Honeywell Powertools® and Demos, Remote Mastermind™ for Mobility remote devicve management |
|
|
Operating Platform |
Microsoft® Windows® Embedded Handheld 6.5 |
|
|
Memory |
256 MB RAM x 512 MB Flash |
|
|
Memory Expansion |
User accessible Micro SD slot with High Capacity (HC) memory card support (up to 32 GB) |
|
|
Scan engine |
Standard Range or extended Range Area Imager/scanner with Laser aimer or High Density Imager with green LED Aimer. All imagers equipped with Adaptus 6.0 Imaging Technology. |
|
|
Symbologies support |
1D Linear |
Codabar, CODE 3 of 9 including PARAF, Interleaved 2 of 5, Code 2 of 5, Matrix 2 of 5, Code 11, Code 93, Code 128, UPC, EAN/JAN, RSS, PLessey, Posicode, Straight 2 of 5 IATA, straight 2 of 5 Industrial, Telepen, Trioptic Code, UCC/EAN-128, UPC-A |
|
2D |
PDF417, Maxicode, Data Matrix, QR Code, Aztec & Code 16K |
|
|
Composite & OCR Codes |
Aztec Mesas, Codablock F, EAN-UCC, RSS-14, OCR-A & OCR-B |
|
|
Postal Codes |
Postnet, Australian, British, Canadian, China, Japanese, KIX (Netherlands), Korea & Planet Code |
|
|
Keyboard |
30-key Numeric or 46-key QWERTY |
|
|
Display |
3.5? high-resolution VGA colour display, full axis viewing, full sunlight readable, with Industrial 4-wire resistive Touch Panel which supports Finger or Stylus touch |
|
|
Camera option |
3.0 megapixel camera, Autofocus, LED Flash |
|
|
I/O Ports |
USB 2.0 |
|
|
Audio |
Speaker, HAC receiver, microphone, vibrator, echo cancelation, Bluetooth® headset support |
|
|
Radio options |
WLAN |
IEEE 802.11 a/b/g/n; Wi-Fi™ certified Security: WEP,802.1x, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPA-PSK, WPA v2.0, PEAP, WAPI, CCXv4 |
|
WPAN |
2.4 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth® V2.1 + EDR; Class II: 10m Line of sight |
|
|
WWAN |
GSM (Voice and Data): 3.9G–HSPA+ (800/850/1900/1700/2100 MHz), GSM/GPRS/EDGE (850/900/1800/1900 MHz) CDMA (Voice and Data): EVDO Rev A – 1xRTT/EVDO (800/1900 MHz) Software definable Gobi 3000 (Data only): 3.9G – HSPA+/UMTS (800/850/900/1700/1900/2100MHz), GSM/GPRS/EDGE (850/900/1800/1900MHz) and EVDO Rev A – 1xRTT/EVDO (800/1900 MHz) |
|
|
GPS |
Integrated autonomous GPS receiver with built-in Assisted-GPS (A-GPS) services and software utilities. |
|
|
Battery |
Standard |
Li-ion 3.7V, 2300mAh |
|
Extended |
Li-ion 3.7V, 4000mAh |
|
|
Hours of Operation |
Standard |
6.5 Hours (Decoding & sending data over WLAN every 9 seconds) |
|
Extended |
12 Hours (Decoding & sending data over WLAN every 9 seconds) 8.5 Hours (Decoding & sending data over WWAN every 15 seconds, GPS continuously receiving data) |
|
|
Sealing |
IP54 rating (Water & Dust Resistant) Independently certified |
|
|
Mechanical Shock |
Drop: Functional multiple drops from 1.5m onto concrete Tumbles: 1600 1 m thumbles per IEC 60068-2-32 specifications |
|
|
Electrical Static Discharge |
Air: 15kVdc Direct: 8kVdc |
|
|
Operating Temp. |
-10 ~ 50°C |
|
|
Storage Temp. |
-20 ~ 70°C |
|
|
Humidity |
up to 95% non condensing |
|
|
Warranty |
1 Year limited Factory warranty |
|
|
H x W x D |
Standard battery |
157 x 76 x 28 mm |
|
Extended battery |
157 x 76 x 33 mm |
|
|
Weight |
Standard battery |
324g |
|
Extended battery |
380g |
|
