The LevelOne FEP-0811 provides 8 x 10/100Mbps ports with IEEE 802.3at PoE plus supported. This switch is IEEE 802.3at/af compliant, and provides power and data over a single Ethernet cable to any PoE device, with total power budget of 123.2W, up to 30W per port. Ideal for desktops and it is also 19-inch rack-mountable, which provides convenient and flexible installation. The FEP-0811 is designed for small businesses that prefer an affordable solution for PoE deploying infrastructure.
Key Features
- IEEE 802.3af/at PoE compliant to simplify deployment and installation
- Auto-detection and protection of non-standard PoE devices
- 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
- 11-inch metal housing with 19-inch rackmount kit included
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Total PoE power budget: 123.2W, up to 30W per port
- Internal power supply
Package Contents
- Power Cord
- 19″ Rackmount Kit
- Quick Installation Guide
System Specifications
Buffer Memory (KB):
64KB
Connectors and Cabling:
8 x 10/100Base-TX RJ-45 PoE Ports
10Base T Cat. 3, 4, 5 UTP/STP
100Base TX Cat. 5 UTP/STP
Button:
Power On / Off Switch
Indicator:
Power, Active, 10/100M, PoE
Transmission Method:
Store-and-Forward
Power:
Power Consumption: < 130W
Power Input: 100-240V AC, 50-60 Hz, 2A Internal Power Supply
Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3x Full-duplex Flow Control
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.3at Power over Ethernet Plus (PoE+)
Physical Specifications
Dimensions (W x D x H mm):
185 x 280 x 44 mm
Weight (g):
1600 g
Performance
Backplane (Gbps):
1.6Gbps
MAC Address Table:
1K
Data Transfer Rate:
10/100Mbps
Packet Forwarding Rate:
100Mbps port – 148,000pps
10Mbps port – 14,880pps
Features
PoE:
Power Budget: Max. 123.2W
PoE Standard: IEEE 802.3af/at Power over Ethernet / PSE
PD classification identity
PoE over current protection
PoE circuit sorting protection
PoE Power Output: Per Port 56V DC, Max. 15.4 watts (802.3af)
or 30 watts (802.3at)
Power Pin Assignment: 1/2(+), 3/6(-
Environment
Temperature (°C):
Operating: 0°C ~ 45°C
Storage: – 40°C ~ 70°C
Humidity (Non-condensing):
Storage: 10% ~ 90%
Operating: 10% ~ 90%
Others
Approval and Compliance:
FCC, CE
Deployment:
Desktop and 19-inch rack-mountable
