Atom N270 Processor 1.6 GHz
Innovative Compact Design
Die-cast aluminium cabinet
Optional SSD drive
Exceptional Energy Efficiency
Mobile Intel ® 945 GSE Express Chipset
Sliding latch provides security
Lock down via Kensington lock
Revolutionary convection cooling solution
Fan-less operation for increased reliability
Energy Star 5.0 qualification
VESA wall mountable
Easy and Efficient Serviceability with single hinged tool free design
?
Memory upgrade | NCR40R1000 | 1GB DDR2 Memory upgrade |
NCR40R2000 | 2GB DDR2 Memory upgrade | |
Expansion cards | NCR40-3USB12 | I/O card /w 3 extra 12V USB and Daughter board |
LCD Display | NCR5942H15-B | 15″ inch LCD Display |
12″ inch LCD Display | ||
Touch Monitors | 15″ inch LCD Capacitive Touch Monitor with Powered USB | |
15″ inch LCD resistive Touch Monitor with Serial Interface | ||
Keyboards | NCR2336 | Small 78-Key Programmable POS Keyboard with 3 Track MSR |
SPOS G86-61411 Black 14″ USB keyboard with 3-track magnetic stripe reader and touchpad. 123 Key QWERTY plus 60 Programmable keys | ||
Cash Drawers | NCRHdr | NCR Compact Hospitality Cash Drawer, Charcoal |
NCRMdr-B | NCR Mid-range Cash Drawer, Dark Grey | |
Printers | NCR Single Station Thermal POS Printer | |
NCR 2-station Hybrid Printer |
CPU | Intel Atom® N270 1.6GHz CPU |
Memory | 1 GB DDR2 RAM expandable to 2 GB (single Slot) |
Storage | Standard with 2.5-inch 160GB SATA Hard Disk Drive |
Connectivity | 4 Powered RS-232 (selectable 0/5/12V) |
1 PS2 Port | |
5 total, expandable to 8 | |
1 x VGA Port 1 x DVI port for LCD Monitor | |
1 Cash Drawer Port (Controls 2 drawers with optional Y-cable) | |
10/100Mb Ethernet Port | |
Expansion slot for proprietary expansion card | |
Operating Systems | Windows ® Embedded POSReady 2009 |
Power management | 150W Power Supply (external) External power supply enables easy swap |
Energy Star 5.0 Qualification | Windows and SLEPOS 11 operating systems purchased from NCR are defaulted to support ENERGY STAR 5.0 power settings. If an operating system is not purchased from NCR, the RealPOS 40 will ship with an open source Linux operating system defaulted to support ENERGY STAR 5.0 power settings for compliance purposes. |
Housing | Die Cast Aluminium |
Diagnostics | 2 Colour LED’s provide diagnostic feedback |
Software Support | NCR OPOS and JavaPOS support |
Serviceability | Open Hinged cabinet Tool free access to internal components Tool free replacement of Hard disk Drive |
Size (W x D x H) | 254 x 226 x 76mm |
Weight | Terminal with power supply: 3.31 Kg |
Operating Temperature | 0 ~ 40°C |
Relative Humidity | 10% ~ 90% non condensing |
Power Supply | 150W-12V External Power supply |
