Opticon M-5 Imager Presentation Scanner in New Zealand
Explore Opticon M-5 Imager Presentation Scanner from ACP Online New Zealand. This product is listed in our Presentation Barcode Scanners range for customers seeking dependable business and technology solutions.
Product information
Automatic Scanning Operation
RS232, PS2 or USB interface
Up to 50 Frames per seconds
Mobile mode reads barcodes from mobile phones
RSS Decoding Capability
IP52 rating
Multiple indicator lights
Light source
Aiming laser diode, illumination LEDs
Scan Method
Illumination omni-scanning mode 625 nm, illumination mobile mode 633 nm, illumination aiming 525 nm, illumination auto trigger 850 nm
Scan rate
Up to 50 fps
Trigger mode
Manual, auto trigger
2D image format
Windows Bitmap, JPEG, TIFF
2D image output mode
4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical)
Min. resolution at PCS 0.9
0.127 mm / 5 mil at Code39 / QR code
0.169 mm / 7 mil at DataMatrix
Depth of field
*0 – 145 mm res. 0.254 mm / 10 mil)*
*15 – 45 mm res. 0.127 mm / 5 mil*
0 – 155 mm res. 0.33 mm / 13 mil
0 – 140 mm res. 0.26 mm / 10 mil
20 – 45 mm res. 0.127 mm / 5 mil
**0 – 40 mm (320×240 pixels)**
at *PDF417* and Code 39 or **mobile code**
Pitch Angle
-55 to 0°, 0 to +55°
Roll (Tilt) Angle
360°
Skew (Yaw) Angle
-50 to -0°, +0 to +50°
Field of view
Horizontal 46°, Vertical 30°
Reading Indicators
Visual: 1 LED (green/blue/orange)
Non-visual: Buzzer
Interface
RS232 – DB9 PTF connector with external power supply
Keyboard Wedge – MiniDIN6 F/M connector with external power supply
USB – Ver. 1.1, HID/VCP, USB-A connector
Symbologies supported
1D: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey, USPS
Postal Code: Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, Postal JPN, POSTNET
2D Code: Aztec Code, Aztec Runes, Composite codes, Codablock F, Data Matrix, (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code
Input voltage
5V ± 10%
Input Current
Max. 150 mA
Operating Temperature
0 to 40 °C
Storage Temperature
-40 to 70 °C
Operating Humidity
5 – 95 % (non-condensing)
Storage Humidity
5 – 95 % (non-condensing)
Ambient light immunity
Fluorescent 10,000 lx max, Direct sun 50,000 lx max, Incandescent 10,000 lx max
Drop Test
1.5 m / 5 ft drop onto concrete surface
Dimensions (W x H x D)
90 x 139 x 96 mm
Weight
295 g
Product Compliance
CE, FCC, VCCI, RoHS
Product details
- Brand: Opticon
- SKU / model reference: M-5
- Product category: POS › Barcode Scanners › Presentation Barcode Scanners
- Catalogue status: Send enquiry to confirm stock and current pricing.
Before ordering
Please confirm model, connection, sizing, consumable or device compatibility where applicable. Product images and references should be checked against your existing equipment before purchase.
