RocketDish is a Carrier Class Dish Antenna that was designed to seamlessly integrate with Rocket M radios (sold separately). Rocket M combines the “brains” in one robust unit; pair Rocket M with RocketDish to create powerful 2×2 MIMO PtP bridging applications. This seamless integration gives network architects unparalleled flexibility and convenience.
Antenna Characteristics
Frequency Range: 5.1-5.8 GHz
Gain: 34 dBi
Hpol Beamwidth: 3 deg. (3 dB)
Vpol Beamwidth: 3 deg. (6 dB)
F/B Ratio: -42 dB
Max VSWR: 1.4:1
Dimensions: 1050 cm diameter (1.05 m)
Weight: 13.5 kg
Wind Survivability: 125 mph
Wind Loading: 256 lb @ 100 mph
Polarization: Dual Linear
Cross-pol Isolation: 35 dB min
ETSI Specification: EN 302 326 DN2
Mounting: Universal pole mount, Rocket M bracket, and weatherproof RF jumpers included
Product Contents
1 x AirMax 30db Dish in brown carton
1 x Dual Polarity Feedhorn
1 x Mounting Bracket
2 x RP-SMA to RP-SMA pigtails
1 x Mounting h/w kit
