Intelligent Bluetooth Wireless Scanner
-
Ruggedized over-mold design to withstand multiple drops to concrete from 1.8 meter
-
Bluetooth 2.1 EDR wireless technology with more than 80m communication coverage
-
Plug-and-play cordless migration by working with smart cradle
-
Support multiple connections up to 7 scanners in PICO mode
-
Support both HID and SPP profiles to connect with most Bluetooth-enabled hosts
-
Memory storage up to 20,000 EAN-13 scans for batch scanning
-
Batch scanning function is ideal for inventory application
-
Support out-of-range scanning and auto-reconnection features
-
Outstanding reading capability on 3 mil barcode with more than 2″ depth of field
-
More than 16″ reading distance on 100% UPC/EAN symbols
-
Unsurpassed readability on low contrast, smudged, poorly-printed or damaged barcodes
-
GS1 DataBar Linear-stacked, PDF, MicroPDF and composite code are supported
?
Model |
F-780BT |
Scan engine |
High Performance Linear Imaging Scanner |
Print Contrast |
20% minimum reflective difference |
Resolution |
Typical 3 mil (Code 39, PCS=0.9) |
Depth of field |
More then 41cm on 100% UPC/EAN symbols More then 61cm on 20 mil Code 39 |
Light Source |
630nm visible red LED |
Scan rate |
Dynamic scanning rate up to 500 scans/sec |
Reading Direction |
Bi-Directional (forward and backward) |
Pitch/Skew |
+/- 65º/65º/55º |
Operating modes |
Trigger & Presentation |
Configuration Setup |
Bar code programming manual |
Windows utility – FuzzyScan PowerTool.net |
|
Data editing |
Condensed Datawizard via bar code programming manual |
Full-feature DataWizard via FuzzyScan PowerTool.net |
|
User Indicators |
Blue link Indicator and 2-colour status indicator Programmable beeper Optional vibrator |
Cordless Communication |
Bluetooth v2.1 EDR |
RF Frequency |
Band 2.402~2.4830 GHz unlicensed ISM Band |
Radio Link Modes |
PAIR Mode, PICO Mode, SPP Mode, HID Mode |
Supported Profiles |
SPP, HID |
Communication Range |
More then 80 meters in open space when working with Smart Cradle, line of sight |
Smart Cradle (HB2110-x) |
RF Standard : Bluetooth v2.1 EDR |
Charging/Batch Cradle (HB2100-x) |
Charging/ Batch Communication cradle. Need to use Bluetooth Dongle for PC Host communications with the Scanner. |
Interface from cradle to PC |
PS/2 (DOS V) Keyboard Wedge Cable |
Barcode Symbologies 1D Linear |
Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic Code 128, UCC/EAN-128, Codabar, Code 11, Code 93 Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5 German Postal Code, China Postal Code, IATA UPC/EAN/JAN, UPC/EAN/JAN with Addendum Telepen, MSI/Plessey & UK/Plessey GS1 DataBar (formly RSS) Linear & Linear Stacked |
Linear stacked |
PDF417, Micro PDF417, Codablock, Composite only on the F-788BT |
Power Source |
3.7V, 2200mAH Li-ion Rechargeable Battery |
Battery charging time |
Approx. 4-5 Hours per full charge (using Power supply) |
Scans per full charge |
More than 45,000 scans and transmissions |
Drop Specifications |
Withstands multiple 1.8m drops to concrete |
Environmental Sealing |
IP41 |
Operating Temperature |
10 ºC to 50 ºC |
Storage Temperature |
-40 ºC to 70 ºC |
Humidity |
5% to 95% related humidity, non-condensing |
Ambient Light Immunity |
0 ~ 100’000 lux |
ESD Protection |
Functional after 15KV discharge |
