Serial Dot Matrix Printing
Up to 2.5 LPS printing speed
Panel Mount
2K Print Buffer
3 ply Printing Capable
Data logging device
Ribbon | IR91B | Black Cassette Ribbon |
Paper | P5757 | Plain Bond Lint Free Paper 57 x 57 mm |
C5757 | 2 Ply Carbonised Paper 57 x 57 mm |
Printing Method | 9 Pin Serial dot Matrix | |
Printing Direction | left to right | |
Number of Columns | 24/40 columns | |
Printing Speed (Max.) | 24 col = approx. 2.5 lines/sec. | |
40 col = approx. 1.8 lines/sec. | ||
Character Size | 24 col = 1.62 × 2.4mm | |
40 col = 1.08 × 2.4mm | ||
Paper feed method | Friction | |
Paper Type | Plain Paper, 2 Ply or 3 Ply | |
Paper Width | 57.5 mm | |
Emulation | ESC/POS, CBM Mode & STAR Mode | |
Print Buffer | 2K | |
Sensors | Paper end sensor | |
Standard Interfaces Available | Serial | RS232c |
Parallel | Centronics | |
Driver available | Windows 2000/NT/XP/2003 server, OPOS | |
Weight | 0.4 Kg | |
External Dimensions (W x D x H) | 115 x 119 x 65 mm | |
Reliability | Mechanism | MCBF 1 million Lines (40 Columns) |
EMC/Safety Standards | UL, C-UL, FCC class A, TUV-GS, CE marking | |
Power Supply (Adapter) | AC adaptor 100/120/230, Output 7V DC 5%, 1.9A |
