Small and compact design
-
Clamshell structure facilitates paper handling and head cleaning
-
Splash-proof design of panel, against vertical drips (Equivalent to IEC60529 IPX1)
-
High speed 150mm/sec printing
-
Durable to low temperature operation down to -20°C
-
Equipped with auto cutter (Full or partial cut)
-
A variety of multiple choices of functions by memory switch
-
Registration of user-defined characters and logos into flash memory
-
Page mode offers to arrange pages freely
-
1D and 2D bar codes available
-
CT-P291: 48~58mm Paper width
-
CT-P293: 58~80mm Paper width
|
Paper for CT-P291 |
T5750 |
Thermal Paper 57 x 50 mm |
|
Paper for CT-P293 |
T8050 |
Thermal Paper 80 x 50 mm |
|
|
CT-P291 |
CT-P293 |
|
Printing Method |
Line Thermal Dot Printing |
|
|
Printing Width |
54mm, 432 dots |
72mm, 576 dots |
|
Printing Speed |
Max. 150mm/sec. |
Max. 150mm/sec. |
|
Number of Columns |
Font A: 34 columns |
Font A: 48 columns |
|
Font B: 45 columns |
Font B: 64 columns |
|
|
Font C: 51 columns |
Font B: 72 columns |
|
|
Character Size |
Font A: 1.25 × 3.00mm (12 × 24 dots) |
|
|
Font B: 0.88 × 2.14mm (7 × 19 dots) |
||
|
Font C 1.00 x 2.00mm (8 x 16 dots) |
||
|
Dot Pitch |
8 x 8 dots/mm (203 dpi) |
|
|
Bar-code type |
UPC-A/E, JAN (EAN) 13/8 columns, ITF, CODE 39, CODE 128, CODEBAR, CODE 93, PDF417, QRCODE |
|
|
Paper feed method |
Friction |
|
|
Line Spacing |
4.23mm (1/6 inch), can be set by a command (Min.1/203 inch) |
|
|
Paper Type |
Thermal |
|
|
Paper Width |
58 × Max. ø50mm |
80 × Max. ø50mm |
|
Emulation |
ESC/POS |
|
|
Print Buffer |
4K/45 bytes |
|
|
Sensors |
Paper end sensor |
|
|
Standard Interfaces |
Serial: RS232c Parallel: Centronics USB |
|
|
Driver available |
Windows 2000/NT/XP/2003 server/WIN 7, OPOS, JavaPOS, POS for .net, CUPS |
|
|
Weight |
0.7 Kg |
0.8 Kg |
|
External Dimensions (W x D x H) |
107 × 120.5 × 109mm |
127 × 120.5 × 109mm |
|
Reliability |
Head: 100,000,000 pulses or 100km |
|
|
Cutter: 1,000,000 cuts |
||
|
EMC/Safety Standards |
FCC class A, TUV-GS, CE marking, C-Tick |
|
|
Power Supply |
DC 24V |
DC 24V |
|
Operating Temp. Range |
-20 ~ 50 °C |
|
|
Storage Temp. Range |
–20 ~ 60 °C |
|
