Sam4s ER-390M Cash Register in New Zealand
Sam4s ER-390M Cash Register is available through ACP Online NZ within our Single Roll Thermal Cash Register collection. Review the information below to confirm that it suits your equipment, application and compatibility requirements.
Product information
High featured Single Station Cash Register
90 Key Programmable Flat Keyboard
High Speed (13.3 LPS) Thermal Printer (57mm paper)
Drop in Paper loading
2 x RS232 (DB9 Female) ports for Scanner, Scale, PC communication, Kitchen/Bar Printer or Journal Surveillance output.
2 Line LCD Operator Display
Up to 5000 PLU's
Graphic Logo print
Electronic Journal up to 3000 lines
Interrupt Cashier Lay-away
18 Character Description
?
Paper
T5750
57mm Thermal Paper Roll Ø50mm (approx 28m)
T5770
57mm Thermal Paper Roll Ø70mm (approx 59m)
Printers
ELLIX-10
57mm Thermal Printer
ELLIX-20
ELLIX-30
ELLIX-40
80mm Thermal Printer
SRP-275
SRP-270
76mm Dot Matrix Printers
Scanners
Handheld Scanners
Opticon, CINO, Honeywell, Posiflex and Datalogic Handheld Scanners; OPR3201 , FBC-780
Presentation Scanners
Opticon, Honeywell, Datalogic and Posiflex, Presentation Scanners; ORBIT , Magellan 1100i
Scanner/Scale
DataLogic Scanner/Scale combinations
Scales
Weight Only Scales
CAS and NCI compatible Weight only scales with RS232 Connection; PD-II , AP1W
Cables
PC Com Cable
PC Communication Cable (2 m)
Printer Cable
Remote Printer Cable (2 m)
Scale Cable
Scale Cable for Weight Only Scales (2 m)
Extension Cable
Convertor Cables for RJ-45 to DB9 Male/Female Adaptor
Misc.
Gender Changer
Serial Port (DB9) Male to Male Connector
USB-Serial Convertor
USB to Serial Convertor (when there is no DB9 Serial Port on the PC)
Ethernet-Serial Convertor
(Port-Server)
Ethernet to Serial Convertor (when a remote data polling over internet is needed
Additional Cable
Additional meters of Serial Cable when longer then 2 meters
Expansion Memory
4 Mbytes Expansion Memory (Maximum 1).
Printing Method
Single Station Direct Thermal Type
Printing Speed (Max.)
up to 13.3 LPS
Paper Width
57.5 ± 0.5mm 69.5 ± 0.5mm 76 ± 0.5mm
Paper Roll Diameter
Max Ø 83.0mm
Paper Supply Method
Easy Paper Loading, Drop in and Print
Keyboard
90 Key Flat Keyboard
Display
Operator:
LCD 2 Lines of 16Characters
Customer
10 Digit VFD
Memory
ROM: 4 Mbits Flash ROM
RAM: 2 Mbits standard, 4 Mbits Optional
Memory Protection
60 Days
Interface
2 x RS232 (DB9 Female)
Drawer
4B/8C
Memory Configuration
("Max." depends on
Memory Sharing
choices )
up to 5000 PLU's
Max. 99 Clerks
Max. 99 Groups
Max. 500 Checks (Accounts)
Max. 100 Lines Record Per Account
Soft (Restaurant Style) or Hard (Service Station Style) Check (Account) System
Max. 2 Price Levels
Max. 99 Mix & Match
Max. 15000 Line Electronic Journal
OS Functions
32 Character per Line Logo Description
(6 Lines Heading + 6 Lines Footing)
18 Character Description
15 Digit PLU Number
5 Modifier Levels
10 Macro keys ( Manager Control Option – New )
10 Tender Keys
Charge Posting Accounts
Max. 4 Currency Conversion
Inventory Item
Condiment Item
Table Management or Clerk Interrupt
Training Mode
6 Digit Clerk Password
Graphic Logo on the Receipt Heading
Max. 100 Line Record per Transaction
Software Utilities
Programming Utility Software, ASCII converter for PC comm's
Weight
13 Kg
External Dimensions
(W x D x H)
400 x 450 x 266 mm
EMC/Safety Standards
CE, FCC, UL, TUV, GS
Power Supply
AC 230V± 10%
Product details
- Brand: Sam4s
- SKU / model reference: ER-390M
- Product category: POS › Cash Registers › Single Roll Thermal Cash Register
- Catalogue status: Send enquiry to confirm stock and current pricing.
Before ordering
Please confirm model, connection, sizing, consumable or device compatibility where applicable. Product images and references should be checked against your existing equipment before purchase.
