- 80mm/sec. printing speed
- Addressable two-colour thermal printing (with special paper)
- 2 Station receipt and Journal
- interface options: Serial & Parallel
- Barcode printing capable
- ESC/POS Compatible
- Auto Paper loading
- Auto cutter on Receipt
?
Paper | T5750 | Thermal 57 X 50 Paper Roll |
T5770 | Thermal 57 x 70 Paper Roll? |
Printing Method | Line Thermal Dot Printing | |
Printing Width | 58mm Paper: 54mm/432 Dot/lines | |
Dot Pitch | 8 x 8 dots/mm (203 dpi) | |
Printing Speed (Max.) | approx. 80 mm/Sec | |
Number of Columns | Font A – 36 columns | |
Font B – 48 columns | ||
Character Size | Font A:1.25 ×3.00mm | |
Font B:0.88 ×2.13mm | ||
Character Table | Alphanumeric Character (Font A & B) | |
Code page 437,850,852,857,860,863,865,866,Katakana,Windows code | ||
Bar-code Type | UPC-A/E,JAN-13/8,ITF,Code 39,Code 128,CODABAR,Code 93 | |
Line Spacing | 4.23mm (1/6 inch), can be set by a command | |
Paper feed method | Friction | |
Paper Type | Thermal Paper Roll | |
Paper Width | 58 ± 0.5mm | |
Paper Roll Diameter | Max Ø 83.0mm | |
Paper Supply Method | Easy Paper Loading, Drop in and Print | |
Emulation | ESC/POS | |
Print Buffer | 8K bytes | |
NV Memory | – | |
Sensors | Paper Near End Sensor, Paper End Sensor , Rear Cover Open Sensor | |
Standard Interfaces Available | Serial | RS-232C |
Driver available | Windows 2000/NT/XP/2003 server, OPOS | |
Weight | Printer: 2.3 Kg, Power adapter: approx. 0.4 Kg | |
External Dimensions (W x D x H) | 128 x 359.5 x 162.5 mm | |
Reliability | Head | 50,000,000 pulses or 50 Km |
Auto cutter | 300,000 cuts | |
EMC/Safety Standards | UL, C-UL, FCC Class A, TUV-GS, CE | |
Power Supply (Adapter) | Input: AC100 ~240V± 10%(include) Output: DC 8.5V | |
