- High Speed Dot Matrix Printing
- Up to 3.1 LPS printing speed
- Easy Loading
- Flat bed Slip Printer
- 3 ply Printing Capable
- Compact Design
- Multiple sensors (top-of-form, bottom-of-form)
Ribbon | RC200B | Black Cassette Ribbon |
RC200P | Violet Cassette Ribbon |
Printing Method | 9 Pin Serial dot Matrix | |
Printing Direction | Bi-directional, Logic seeking | |
Number of Columns | 42 col. (7 × 9 font), 35 col. (5 × 9 font) | |
Printing Speed (Max.) | approx. 3.1 Lines/Sec | |
Fonts | PC437, PC850 and International | |
Character Size | 7 × 9 font (half): 1.2 × 2.42mm | |
5 ×9 font (2 pulses per dot): 1.5 × 2.42mm | ||
5 ×9 font (3 pulses per dot): 2.1 | ||
Paper feed method | Friction | |
Paper Type | Plain Paper, 2 Ply or 3 Ply | |
Paper Width | 80 to 182mm (W) × 80 to 257m | |
Original + 2 copies / Thickness: 1 ply 0.09 to 0.2mm | ||
Duplicates 0.12mm to 0.25mm | ||
Paper Supply Method | Auto Paper loading, | |
Emulation | ESC/POS, CBM Mode & STAR Mode | |
Print Buffer | 2K or 35 bytes | |
Sensors | Paper out top-of-form, bottom-of-form sensors | |
Drawer Ports | 2 ports | |
Standard Interfaces Available | Serial | RS232c |
Driver available | Windows 2000/NT/XP/2003 server, OPOS | |
Weight | 2.1 Kg | |
External Dimensions (W x D x H) | 180 x 190 x 138 mm | |
Reliability | Mechanism | MCBF 2.5 million Lines |
Printhead | 70 million Characters | |
EMC/Safety Standards | UL, C-UL, FCC class A, TUV-GS, CE marking | |
Power Supply (Adapter) | AC adaptor (31 AD) 100/120/230, Output 24V DC 5%, 1.9A | |
